| Indoor model |
坐吊机内机 |
| Power supply |
V-ph-Hz |
440-3-60 |
| Cooling |
Capacity |
Btu/h |
48000 |
| Input |
W |
5191 |
| Current |
A |
9.2 |
| EER |
W/W |
2.71 |
| Heating |
Capacity |
Btu/h |
52000 |
| Input |
W |
4763 |
| Current |
A |
8.5 |
| COP |
W/W |
3.2 |
| Indoor fan motor |
Model |
|
|
| Old Model |
|
YDK125-6E |
| Qty |
|
1 |
| Input |
w |
209/145/121 |
| Capacitor |
uF |
5UF/450V |
| Speed(hi/mi/lo) |
r/min |
775/610/540 |
| Indoor coil |
a.Number of rows |
|
3 |
| b.Tube pitch(a)x row pitch(b) |
mm |
21x13.37 |
| c.Fin spacing |
mm |
1.4 |
| d.Fin type (code) |
|
Hydrophilic aluminium |
| e.Tube outside dia.and type |
mm |
Φ7,innergroove tube |
| f.Coil length x height x width |
mm |
2080x210x40.11 |
| g.Number of circuits |
|
10 |
| Indoor air flow (Hi/Med/Lo) |
m3/h |
1900/1600/1400 |
| Sound level (sound pressure) |
dB(A) |
53/48/44 |
| Throttle type |
|
/ |
| Indoor unit |
Dimension (W x Dx H)(body) |
mm |
840x840x245 |
| Packing (W x Dx H)(body) |
mm |
900x900x257 |
| Dimension (W x Dx H)(panel) |
mm |
950x950x55 |
| Packing (W x Dx H)(panel) |
mm |
1035x1035x90 |
| Net/Gross weight(body) |
kg |
27/32 |
| Net/Gross weight(panel) |
kg |
5/8 |
| Design pressure |
MPa |
4.2/1.5 |
| Drainage water pipe dia. |
mm |
ODΦ32 |
| Refrigerant piping |
Liquid side/ Gas side |
mm |
Φ9.52/Φ19(3/8"/3/4") |
| Controller |
|
Remote control |
| Operation temperature |
℃ |
17~30 |
| Room temperature |
Cooling |
℃ |
17~32 |
| Heating |
℃ |
0~30 |
| Qty’per 20’ /40’ /40'HQ |
indoor unit+panel |
128/268/294 |
